2. Product mode

Channel	Mode (Analog channel+Digital channel)		Playback
	No	Channel number*Resolution/Frame rate	Channel number*Resolution/Frame rate
32CH	1	32 * 1080N/15 + 0	8 * 1080N/15
	2	24 * 1080N/25 + 8 * 1080P/25	8 * 1080P/25
	3	16 * 1080N/25 + 16 * 1080P/25	8 * 1080P/25
	4	8 * 1080N/25 + 24 * 1080P/25	8 * 1080P/25
	5	0 + 32 * 1080P/25	8 * 1080P/25

Note:The capture function is supported.


3.Technical parameters

System	Compressed format	H.264
	Operating System	embedded Linux
Video	Maximum Input	32
	VGA output	Yes
	BNC output	Yes
	Loop output	No
	HDMI output	Yes
Audio	Audio in	16
	Audio out	1
	Two-way intercom	Yes
Record	Real-time video frequency	16ch is not real time
	Record mode	Timing, manual, dynamic detection, external alarm
Playback	Maximum Playback	8
	Search ways	Time point retrieval, calendar retrieval, event retrieval, channel retrieval
Backup	USB mobile hard disk,  U disk	Yes
	USB DVD burner	Yes
	Format	DAV、AVI
Remote view	Browser	Supports multiple web browsers
	CMS	CMS3.0
	APP	iPhone, Android
Alarm	Alarm In	16
	Alarm Out	4
Store	HDD number	8
	E-SATA	No
PTZ	Interface	1*RS485
	Protocol	PELCOP,PELCOD,LILIN,MINKING,NEON,STAR,VIDO,DSCP,VISCA,SAMSUNG,RM110,HY
	Control ways	Pan, Tilt, Zoom, Preset, Cruise, Trace
Network	Network Interface	10 / 100 Mbps Ethernet (RJ-45)
	Protocol	TCP/IP, DHCP, DDNS, NTP, SMTP
Others	Remote	Yes
	Power Supply	DC12V /4A
	Work Temperature	-10°C ~60°C
	Work Humidity	10% ~ 90% Humidity
