2. Product mode

Channel	Mode （Analog channel + Digital channel）		Playback	Preview （Analog channel + digital channel）
	No	Number of lines * resolution / frame rate	Number of lines * resolution / frame rate	Preview the number of frames
8CH	1	8 * 5M/11 + 0	4 * 5M/11	8 * 5M/20 + 0
	2	4 * 5M/11 + 4 * 5M/25	4 * 5M/25	4 * 5M/20 + 4 * 5M/25
	3	0 + 16 * 1080P/25	8 * 1080P/25	0 + 16 * 1080P/25
	4	0 + 8 * 3M/25	8 * 3M/25	0 + 8 * 3M/25

Note:The capture function is supported.
5M maximum frame rate of 11 frames; 4M maximum frame rate of 15 frames; 3M maximum frame rate of 20 frames;


3.Technical parameters

System	Compressed format	H.264
	Operating System	embedded Linux
Video	Maximum Input	8
	VGA output	Yes
	BNC output	Yes
	Loop output	No
	HDMI output	Yes
Audio	Audio in	8
	Audio out	1
	Two-way intercom	Yes
Record	Real-time video frequency	8CH is not real time
	Record mode	Timing, manual, dynamic detection, external alarm
Playback	The number of simultaneous playback	8
	Search ways	Time point retrieval, calendar retrieval, event retrieval, channel retrieval
Backup	USB mobile hard disk,  U disk	Yes
	USB DVD burner	Yes
	Format	DAV、AVI
Remote view	Browser	Supports multiple web browsers
	CMS	CMS3.0
	APP	iPhone, Android
Alarm	Alarm In	4
	Alarm Out	1
Store	HDD number	2
	E-SATA	No
PTZ	Interface	1*RS485
	Protocol	PELCOP,PELCOD,LILIN,MINKING,NEON,STAR,VIDO,DSCP,VISCA,SAMSUNG,RM110,HY
	Control ways	Pan, Tilt, Zoom, Preset, Cruise, Trace
Network	Network port	10 / 100 Mbps Ethernet (RJ-45)
	Network protocol	TCP/IP, DHCP, DDNS, NTP, SMTP
Others	Remote	Yes
	Power Supply	DC12V /4A
	Work Temperature	-10°C ~60°C
	Work Humidity	10% ~ 90% Humidity
